Fully Automatic Three-Sided Sealing/Double Self-Supporting Bag/Double Zipper/DoubleCutting/Non-Stop Feeding Bag Making Machine (Seven Servos)

Category：Bag Making Machine；Model：HS-600SZL-A

Fully Automatic Three-Sided Sealing/Double Self-Supporting Bag/Double Zipper/Double Cutting/Non-Stop FeedingBag Making Machine (Seven Servosjeven the bottom stand bag,zipper bag making machine by the trilateral bag making machine.double zipper heat sealing parts, double stand attached parts, foldput material frame and the multimedia industrial computer and ACdigital servo control system.

Model	HS-600SZL-A
Sealing Method	Trilateral closure, two independent, double zipper
Machine Speed	Trilateral closure 20-180 segment/min
	Stand-up pouches 20-120 segment/min
	Zipper bag 20-110 segment/min
Feed Rate	35m/min
Traction Servo	6station 0.75kw/1Kw/1.5kw
	2kw/1.5kw/1.5kw
Host Frequency	4Kw Servos
Motor	Cycloid reducer 180W 2 sets
Host Frequency	400W 2 sets
Roll Film Width	maximum 1200mm
Film Roll Diameter	maximum 800mm
Bag Length	60-300mm
Bag Width	50-580mm
Machine Size	16000x1800x2100mm
Machine Weight	8500KG
